China Tyton bend 22.5° manufacturers and suppliers

Tyton bend 22.5°

Short Description:

Send email to us Download as PDF

Product Detail

Serve to Global Premium Pipe Supplier

Shipping and Packaging

Inspect the Goods and Certificate

Exhibition

Product Tags

Application

TYTON fittings for drinking water and neutral liquids up to +70°C

Technical characteristcs

Body – Ductile cast iron EN-GJS-500-7
According to DIN EN 545/598/BS4772/ISO2531 standards
Maximum working pressure PN16
Working temperature: 0˚C- +70˚C
Epoxy coating RAL5015 250 μm thickness or other coating based on request
Push-on socket gaskets made from EPDM/NBR rubber

Dimensions

DN	L	E	Kg
80	40	7	7.3
100	40	7.2	9.3
125	50	7.5	12.6
150	55	7.8	15.9
200	65	8.4	24
250	75	9	33.5
300	85	9.6	44.5
350	95	10.2	58
400	110	10.8	74
450	120	11.4	95
500	130	12	111
600	150	13.2	157
700	175	14.4	217
800	195	15.6	287
900	220	16.8	373
1000	240	18	470
1100	260	19.2	643.7
1200	285	20.4	716
1400	260	22.8	933
1500	270	24.0	1259
1600	280	25.2	1627

Previous: Tyton bend 45°

Next: Tyton bend 11.25°

Dinsen Impex Corp. is a professional supplier and manufacturer for Cast Iron Pipes, Fittings, Couplings which was used for sewer drainage system of buildings. All our products are meet USA and European standard EN877, DIN19522, BS416, BS437, ISO6594, ASTM A888, CISPI 301, CSA B70, GB/T12772.

With a team of skilled and experienced members, we are capable of providing high quality cast iron pipe. Before supplying we make sure that cast iron pipe are strong and durable with accurate measurements and long service life.

Dinsen Impex Corp goal is to supply products with the best services, best quality and the competitive price and satisfy the requirements of clients from domestic and abroad. We believe that our company will have a speed develop with the support from both at home and abroad.We sincerely hope to establish long term and mutual beneficial cooperation with any buyer and friend all over the world !

Transportation: Sea freight, Air freight, Land freight

We can flexibly provide the best transportation method according to customer needs, and try our best to reduce customers’ waiting time and transportation costs.

Type of Packaging: Wooden pallets, steel straps and cartons

1.Fittting Packaging

2. Pipe Packaging

3.Pipe Coupling Packaging

DINSEN can provide customized packaging

We have more than 20⁺ years experience on production. And more than 15⁺ years experience to develop oversea market.

Our clients are from Spain, Italy, France, Russia, USA, Brazil, Mexican, Turkey, Bulgaria, India, Korea, Japan, Dubai, Iraq, Morocco, South Africa, Thailand, Vietnam, Malaysia, Australia, German and so on.

For quality, don’t need to worry, we will inspect the goods twice before delivery . TUV, BV, SGS, and other third party inspection are available.
